RIU00272K5-20TG
설명
RIU00272K5-20TG is 2.5kW 1 channels, 100 to 2500W output power, microwave generator designed ideally for microwave heating and plasma generation applications. The RIU00272K5-20TG provides continuous wave (CW) and or pulse output power adjustable from 1W to 2500W at 27.12MHz. The RIU00272K5-20TG is a remote-type microwave generator system with the SSPA head and power supply unit separately, RIU00272K5-20TG is the industry’s most cost-effective solution providing greater system flexibility. It delivers performance repeatability and reliability you can bank on.
View Product Specification
MW Heating and Drying
Medical Equipment
Semiconductor Equipment PVD, PECVD, Etch
제품 사양
| Min Freq.(MHz) | 25.8MHz |
|---|---|
| Max Freq.(MHz) | 28.5MHz |
| Output Power(W) | 2500W |
| DC RF Efficiency(%) | 70% |
| Drain Efficiency(%) | 2500% |
| RF Output Connector | 7/16" DIN |
| Cooling | Water |
