Enhancing Tactical Data Links with RFHIC’s GaN Solutions: The Future of Military Communications

What is a Tactical Data Link?

A Tactical Data Link (TDL) is a critical communication system in military operations that connects various military assets such as aircraft, ships, ground forces, drones, and command centers in real time. TDL plays a vital role in enabling the quick analysis and response to complex battlefield situations, making it an essential technology in modern military operations.



Key Features of Tactical Data Links

1. Real-Time Information Sharing:
TDL allows the real-time transmission of battlefield information, enabling quick and accurate information sharing between units. This helps commanders and troops to quickly understand battlefield conditions and take immediate action.

2. Multi-Platform Communication:
TDL supports communication between diverse military platforms such as aircraft, ships, ground forces, drones, and command centers. This ensures that all assets are connected and able to share information in real time, allowing for strategic decision-making based on a unified understanding of the situation.

3. Secure and Encrypted Communication:
Security is essential in military communications. TDL employs encrypted communication to prevent external eavesdropping or hacking while also ensuring secure communication in the face of enemy jamming attempts.

4. Automated Data Processing:
TDL automatically processes collected data and delivers relevant information to each unit in real time. This reduces decision-making time and increases the accuracy of data, maximizing operational success.

5. Support for Network-Centric Warfare:
TDL plays a critical role in Network-Centric Warfare (NCW), connecting all military assets in a network to share battlefield information and execute coordinated operations.



Applications of Tactical Data Links

TDLs are used across various military fields:

1. Aerial Operations:

Real-time communication between fighter jets and unmanned aerial vehicles (UAVs) enables the quick sharing of enemy movements and operational information, allowing for fast and effective responses.

2. Naval Operations:

Ships use TDL to communicate with other military assets, share critical information during maritime operations, and adjust operational plans based on enemy positions.

3. Ground Operations:

Ground forces use TDL to connect in real time with assets such as drones, armored vehicles, and tanks, enabling effective operations by understanding enemy positions and terrain.

4. Joint Operations:

In joint operations involving multiple military assets, TDL facilitates smooth communication and collaboration between units, supporting strategic responses.



RFHIC's High-Performance GaN Solutions : Maximizing Military Communication System Performance

RFHIC offers Gallium Nitride (GaN) on Silicon Carbide (SiC) solutions that maximize the performance of tactical data link systems. These solutions provide high power, exceptional energy efficiency, and wide bandwidth to optimize the performance of military communication systems.



Key GaN Solutions from RFHIC:

1. GaN High Power Amplifiers (HPA):
RFHIC’s GaN HPAs play a critical role in transmitting military communication data over long distances. RFHIC's HPA products offer higher power density than traditional Silicon (Si)-based technologies, allowing for compact and efficient system configurations.

Part Number	Freq[MHz] Min~Max	Gain [dB]	Pout [W]	Eff. [%]	Pulse Droop [dB]	Duty [%]	Pulse Width [us]	Vds [V]	Dimensions  W*H*D mm
RRP131K0-10	1200 ~ 1400	54	1200	50	0.5	20	500	12/50	250*150*28
RRP27312K5-30	2700 ~ 3100	30	2800	40	0.5	10	100	6/50	175*234*25
RRP54591K2-42	5400 ~ 5900	42	1200	35	1	10	100	6/50	190*99*23
RRP9397400-56A	9300 ~ 9700	54	400	25	1	10	100	5/6/50	220*120*23



2. GaN Hybrid Amplifiers:
Tailored for the defense industry, hybrid amplifiers provide high efficiency and reliability across multiple frequency bands, enabling the effective management of communication across various platforms within a tactical data link system.

Part Number	Band	Freq[MHz] Min~Max	Type	Type Output Power	Operating Mode	Power Gain [dB]	PAE [%]	VDC
PRM33060-4S	S-band	3100~3500	PP-3G	65	Pulse CW	32	61	46
HR5459-25C	C-band	5400~5900	-	25	-	15	40	28
HR9395-30A	X-band	9300~9500	-	30	-	10	40	50
HR9395-08A	X-band	9300~9500	-	6	-	11	45	48



Advantages of RFHIC's GaN Solid-State Technology

1. High Power Performance:
RFHIC's GaN technology delivers high output with lower power consumption, enabling long-distance communication in crucial environments. This is particularly advantageous for communications between aircraft, drones, and ground forces over extended ranges.

2. Superior Efficiency:
GaN-based amplifiers offer significantly improved energy efficiency compared to traditional technologies, reducing power consumption and ensuring stable communication over extended periods—critical for prolonged military operations.

3. Wide Frequency Bandwidth:
RFHIC's hybrid amplifiers handle a wide range of bandwidths, allowing seamless operation in complex network environments where multiple assets are communicating simultaneously.

4. Exceptional Durability:
GaN on SiC technology provides outstanding durability, ensuring stable performance even in extreme battlefield conditions such as high heat, shock, and humidity, thus enhancing the reliability of military communication systems.

5. Compact and Lightweight:
GaN technology offers high power density while reducing size and weight, improving mobility and ease of installation—ideal for compact tactical equipment.

Conclusion

RFHIC's GaN on SiC solutions redefine the capabilities of tactical data link systems, which are vital to military communications. With its high output power, superior energy efficiency, and wide bandwidth capabilities, RFHIC’s GaN Solid-State solutions can deliver exceptional performance, ensuring dependable and long range communications.  With the integration of RFHIC’s GaN solid-state solutions, cusotmers can achieve more stable and secure communications.  For those aiming to enhance operational effectiveness and future-proof their communications with cutting-edge technology, Please contact RFHIC to fill out the form below to learn more.
