RRP2735160-35

Description

RFHIC’s RRP2735160-35 is an S-band, 180W, gallium-nitride (GaN) Power Amplifier designed for radar systems applications. Operating from 2700 to 3500 MHz, the RRP2735160-35 achieves 35dB of gain with an efficiency of 40%. The RRP2735160-35 is designed using RFHIC’s gallium-nitride on silicon carbide (GaN-on-SiC) high-electron-mobility (HEMT) technology in higher breakdown voltage, wider bandwidth, and higher efficiency. The RRP2735160-35 achieves a duty of 20% and a pulse width of 2000 us. Both RF ports have integrated DC-blocking capacitors and are fully matched to 50 Ohms.
